SANSUI AU-D707F Extra Integrated 100W Amplifier

Key Specifications & Features

• Power output: 100 W + 100 W into 8 Ω (10 Hz–20 kHz, THD 0.003 %)

• Also rated: 100 W + 100 W into 8 Ω (1 kHz, THD 0.002 %)

• Total harmonic distortion: ≤ 0.003 % (8 Ω)

• Intermodulation distortion (SMPTE 60Hz:7kHz = 4:1): ≤ 0.003 % (8 Ω)

• Output band-width (both channels active, THD ≤ 0.02 %): 5 Hz ~ 80 kHz (8 Ω)

• Damping factor (20 Hz–20 kHz, 8 Ω): 100

• Frequency response (1 W): DC ~ 300 kHz (+0/-3dB)

• Slew rate: ± 200 V/µs (8 Ω)

• Rise time: ~0.5 µs

• Phono stage (MM): Sensitivity 2.5 mV / 47 kΩ; Phono MC (Low/High): 100 µV / 300 µV (100 Ω)

• Maximum allowable phono input: MM 200 mV; MC 25 mV (Low position)

• RIAA deviation (MM): ± 0.2dB from 20 Hz to 300 kHz

• Signal-to-noise ratio (A weighted): Phono MM ≥ 90dB; Phono MC ≥ 74dB; Tuner/Aux/Tape ≥ 110dB

• Tone control: Bass ±10 dB at 50 Hz; Treble ±10 dB at 10 kHz

• Tone selector frequencies: Bass 150Hz/300Hz; Treble 3kHz/6kHz

• Filters: Low filter 16 Hz (-3dB, 6dB/oct); High filter 20 kHz (-3dB, 6dB/oct)

• Muting switch: -20dB

• Rated power consumption: 250 W (Japan spec)

• Dimensions: Width ~ 460 mm × Height ~ 160 mm × Depth ~ 404 mm

• Weight: ~ 14.7 kg

🎵

• Very clean amplifier with ultra-low distortion and broad bandwidth – capable of high fidelity performance.

• Comprehensive phono section (MM + MC) with very accurate RIAA and strong performance for vinyl enthusiasts.

• Strong build and vintage design, making it a desirable piece for serious vintage hi-fi systems.
